Power supply voltage: 220V±10% 50Hz±0.5Hz
Temperature control range: 0~50±0.1℃ (display 0.01℃)
Cooling power: 1.2kW
Heating power: 1.8kW-2kW
Maximum extension: 150cm / 200cm
Extension speed: 5cm±0.25cm/min; 1cm±0.05cm/min
Dimensions: 2050/2550 × 440 × 900mm
Test mold: Brass (Optional)
?
Frequently Asked Questions
What is the required power supply for this device?
The instrument operates on a power supply voltage of 220V±10% at 50Hz±0.5Hz.
What is the maximum extension capability?
The maximum extension length is available in two specifications: 150cm and 200cm.
How accurate is the temperature control system?
The system features high-precision control with a range of 0~50±0.1℃ and a display accuracy of 0.01℃.
Does the instrument include test molds?
Test molds made of brass are optional. They are typically provided in groups of three and include extension or elastic recovery specifications.
What are the available extension speeds?
The machine supports speeds of 5cm±0.25cm/min and 1cm±0.05cm/min.
What should be checked during regular maintenance?
Maintenance should focus on regular cleaning of asphalt residue, checking mechanical wear on screws and guide rails, and performing periodic calibration.
